Amtrol 10 GPM High-Performance Pressurizer Water Pressure Booster System - Model RP-10HP
Anybody can pump up pressure with standard off-the-shelf pump and tank components, however AMTROL® does it right. The AMTROL® High Performance Pressurizer® has been designed from the ground up specifically for pressure boosting applications. The High Performance Pressurizer includes the Amtrol'R® Digital Control. It combines the simple operation of a traditional pressure switch but features a digital pressure display, push-button settings and built-in safety features.
The AMTROL High Performance Pressurizer® is a true whole house pressure boosting system. The units are pre-assembled with a low-suction cutoff, thermal overload protection and built-in junction box. The Pressurizer includes a properly sized pressure tank to reduce pump cycling. This decreases power consumption while drastically improving motor life. Unlike small in-line models, this pressure tank provides additional water storage to meet peak water demands while improving efficiency.
Features
- Stainless-steel pump head
- Components and capabilities normally found in commercial systems
- 115/230v compatible
- Boost capabilities up to 40psi over city pressure
- Includes pressure and temperature safety switches
- Quiet operation (65dB)
- 2-year Limited Warranty
Specifications
- Wired for single-phase 115 VAC
- Can be re-wired to be used with 230 VAC
- Pump power must be on a separate circuit (115 Volt Requires 20 Amp Circuit/230 Volt Requires 15 Amp Circuit)
| Model # |
Tank Volume |
Max Pressure Boost |
A Diameter |
| RP-10HP |
14 Gallons |
40 PSI |
17" |
| B Height |
Min Inlet Flow |
Min Water Main Meter Size |
Shipping Weight |
| 30" |
10 GPM |
3/4" |
50 lbs |
Note: Special Order Item
