PS-203 HM Digital Panel Mount Dual Display Dual TDS Controller

The PS-202 allows for continuous and simultaneous monitoring and control of TDS levels on two water lines.

Features

• Simultaneously monitors and controls the TDS levels of two water lines (e.g., the feed water and product water) for high output commercial systems.
• Large, bright L.E.D. displays.
• An alarm will sound if the TDS level rises above the user-set level for both lines.
• Installs easily in minutes.
• Includes two 1/2" sensor probes.

Specifications

• Range: 0 - 999ppm
• Accuracy: +-2%
• Conversion Factor: NaCl (avg. 0.5)
• Resolution: 1 PPM
• ATC: Yes (1 - 65 degrees Celsius)
• Calibration: Adjustable
• Setting: Controlled by on-screen up/down buttons
• Relay Control: The unit will open or close a circuit via dry contacts when the ppm level of the output water (line 2) or input water (line 1) reaches or exceeds its control setting (simple switch). The PS-202 can be used to control one or two pumps, solenoid valves or other device.
• Relay Voltage: 5V
• Alarm: Steady beep for both lines
• Display: Bright 5/8" L.E.D. dual displays
• 2 Probes: 1/2" bushing, 3 meter (9.8 ft) shielded cable
• Power supply: AC 110V / AC 220V
• Dimensions: 9.4 x 9.4 x 12.5 cm (3.7 x 3.7 x 4.9 in.)
• Monitor Weight: 569.8 g (1 lb 4.1 oz)
• Total Weight: 938.4 g (2 lbs 1.1 oz)
